APD220A | Diesel Generator In Bangladesh

Aksa power generation system, providing optimum performance, and reliability, for stationary standby, prime power, and continuous duty applications. All generator sets are factory build, and production tested.

Certificate

TS ISO 8528
TS ISO 9001-2008
CE
SZUTEST
2000/14/EC

General Characteristics

Model Name	APD 220 A
Frequency (Hz)	50
Fuel Type	Diesel
Engine Made and Model	AKSA - A6CRX97TI
Alternator Made and Model	Aksa - AK 4160
Control Panel Model	DSE 6020
Canopy	ASM 7

3 Phase, 50 Hz, PF 0.8

VOLTAGE	STANDBY RATING (ESP)		PRIME RATING (PRP)		Standby Amper
VOLTAGE	kVA	kW	kVA	kW	Standby Amper
400/231	220	176.00	200	160.00	317.55

STANDBY RATING (ESP) : Applicable for supplying power to varying electrical load for the duration of power interruption of a reliable utility source. ESP is in accordance with ISO 8528-1. Overload is not allowed.

PRIME RATING (PRP) : Applicable for supplying power to varying electrical load for unlimited hours. PRP is in accordance with ISO 8528-1. 10 % overload capability is available for a period of 1 hour within 12-hour perod of operation.

ENGINE SPECIFICATIONS

Engine		AKSA
Engine Model		A6CRX97TI
NO. OF CYLINDERS AND BUILD		6 cylinders - in line
BORE AND STROKE	mm	126 X 130
TOTAL DISPLACEMENT	L	9,73
Aspiration		Turbo Charged and Intercooled(Water to Air)
COMPRESSION RATIO		16.5:1
RATED SPEED (RPM)	d/dk	1500
OIL CAPACITY	L	16
Standby Power (kW/HP)		252/338
Block Heater QTY
		1
Block Heater Power (Watt)
		1500
Fuel Type
		Diesel
Injection Type and System
		Direct
Type of Fuel Pump
		P pump
Governor System
		Electronic
Operating Voltage (Vdc)
		24 Vdc
Battery and Capacity (Qty/Ah)
		2x120
Cooling Method
		Water Cooled
Cooling Fan Air Flow (m3/min)
		450
Coolant Capacity (engine only / with radiator) (lt)
		/65
Air Filter
		Dry Type
Fuel Cons. Prime With %100 Load (lt/hr)
		54.1
Fuel Cons. Prime With %75 Load (lt/hr)
		40.6
Fuel Cons. Prime With %50 Load (lt/hr)
		27.1

ALTERNATOR SPECIFICATIONS

Manufacturer		Aksa
Alternator Made and Model		AK 4160
Frequency (Hz)	Hz	50
Power (kVA)	kVA	200
DESIGN		Brushless
VOLTAGE	V	400
Phase		3
A.V.R.		SX440
Voltage Regulation	(+/-)	1
Insulation System		H
Protection		IP22
Rated Power Factor		0.8
WEIGHT COMP. GENERATOR (Kg)		626
COOLING AIR (m³/min)	m3	30.84

SIZE and WEIGHT

Open Type	DRY WEIGHT (kg.) (kg.)	LENGTH (mm.)	WIDTH (mm.)	HEIGHT (mm.)	TANK CAPACITY (lt.) (Lt.)
	-	-	-	-
CANOPY	DRY WEIGHT (kg.) (kg.)	LENGTH (mm.)	WIDTH (mm.)	HEIGHT (mm.)	TANK CAPACITY (lt.) (Lt.)
ASM 7	2980	3918	1463	2163	526

STANDARD SPECIFICATIONS

Water cooled, Diesel engine
Radiator with mechanical fan
Protective grille for rotating and hot parts
Electric starter and charge alternator
Starting battery (with lead acid) including rack and cables
Engine coolant heater
Base frame design incorporates an integral fuel tank and anti-vibration isolators
Flexible fuel connection hoses
Single bearing, class H alternator
Industrial exhaust silencer and steel bellows supplied separately(for open sets)
Static battery charger
Manual for application and installation

OPTIONAL EQUIPMENTS
ENGINE
Fuel-Water Seperator Filter
Oil heater
ALTERNATOR
Anti-Condensation Heater
Main line circuit breaker
CONTROL SYSTEM
Charge Ammeter
TRANSFER SWITCH
Three Pole Contactor
Four Pole Contactor
Three or four pole motor operated circuit breaker
OTHER ACCESSORIES
Main Fuel Tank
Automatic or manual fuel filling system
Manual oil drain pump
Low and high fuel level alarm
Enclosure: weater protective or sound attenuated
Trailer
Tool kit for maintenance
