Full Specification of APD 25 BD Diesel Generator:

Product: AKSA (Powered by Baudouin)

Alternator: AK 218

CONTROL SYSTEM: DSE 6120

Aksa power generation system, providing optimum performance, and reliability, for stationary standby, prime power, and continuous duty applications. All generator sets are factory build, and production tested.

Certificate

• TS ISO 8528
• CE
• SZUTEST
• 2000/14/EC

General Characteristics

3 Phase, 50 Hz, PF 0.8

STANDBY RATING (ESP) : Applicable for supplying power to varying electrical load for the duration of power interruption of a reliable utility source. ESP is in accordance with ISO 8528-1. Overload is not allowed.

PRIME RATING (PRP) : Applicable for supplying power to varying electrical load for unlimited hours. PRP is in accordance with ISO 8528-1. 10 % overload capability is available for a period of 1 hour within 12-hour perod of operation.

ENGINE SPECIFICATIONS

ALTERNATOR SPECIFICATIONS

SIZE and WEIGHT

STANDARD SPECIFICATIONS

Water cooled, Diesel engine
Radiator with mechanical fan
Protective grille for rotating and hot parts
Electric starter and charge alternator
Starting battery (with lead acid) including rack and cables
Engine coolant heater
Base frame design incorporates an integral fuel tank and anti-vibration isolators
Flexible fuel connection hoses
Single bearing, class H alternator
Industrial exhaust silencer and steel bellows supplied separately(for open sets)
Static battery charger
Manual for application and installation

OPTIONAL EQUIPMENTS

ENGINE

• Fuel-Water Seperator Filter
• Oil heater

ALTERNATOR

• Anti-Condensation Heater
• Over sized alternator
• PMG excitation + AVR
• Main line circuit breaker

CONTROL SYSTEM

• Automatic synchronising and power control system ( multi gen-set Parallel )
• Transition synchronization with mains
• Remote annunciator panel
• Remote relay output
• Alarm output relays
• Remote communication with modem
• Earth fault, single set
• Charge Ammeter

TRANSFER SWITCH

• Three Pole Contactor
• Four Pole Contactor
• Three or four pole motor operated circuit breaker

OTHER ACCESSORIES

• Main Fuel Tank
• Automatic or manual fuel filling system
• Manual oil drain pump
• Electrical oil drain pump
• Low and high fuel level alarm
• Residential silencer
• Enclosure: weater protective or sound attenuated
• Duct adapter ( on radiator)
• Inlet and outlet motorised louvers
• Inlet and outlet acoustic baffles
• Trailer
• Tool kit for maintenance
• Automatic transfer switch

Exploring the APD 25 BD Diesel Generator: Powering a World of Possibilities

In a world driven by technology and powered by electricity, diesel generators play a vital role in ensuring a consistent and reliable power supply. The APD 25 BD diesel generator is one such powerful and versatile machine that has garnered attention for its efficiency, durability, and ability to provide electricity in various applications. In this blog, we'll delve into the features and benefits of the APD 25 BD diesel generator and explore the different scenarios where it shines.

Unraveling the APD 25 BD Diesel Generator

The APD 25 BD diesel generator is a robust and compact power solution designed to deliver a reliable source of electricity in diverse settings. Let's take a closer look at its key features:

Power Output: The APD 25 BD offers a power output of 25 kilowatts, making it suitable for both residential and commercial use. It can easily support essential appliances, machinery, and even entire buildings during power outages or in off-grid locations.

Efficiency: Powered by a diesel engine, this generator is known for its fuel efficiency and can run for extended periods without frequent refueling. This feature is essential for scenarios where a continuous power supply is critical.

Durability: Built with high-quality materials and a sturdy design, the APD 25 BD is a durable machine that can withstand harsh environmental conditions. It's well-suited for use in construction sites, remote areas, and as backup power in critical facilities.

Soundproofing: Noise pollution is a concern in many settings. The APD 25 BD is equipped with soundproofing technology, which significantly reduces the noise generated during operation, making it suitable for residential areas and noise-sensitive applications.

Digital Control Panel: This generator is user-friendly, with a digital control panel that allows easy monitoring and control of the unit. This feature simplifies the operation and maintenance of the generator.

Applications of the APD 25 BD Diesel Generator

The versatility of the APD 25 BD diesel generator opens up a wide range of applications. Here are some scenarios where this generator can shine:

Residential Backup Power: In areas prone to power outages or with unreliable electricity supply, the APD 25 BD can provide seamless backup power for homes, ensuring that essential appliances and heating/cooling systems continue to function during outages.

Construction Sites: Construction sites often lack a stable power source. The APD 25 BD can power heavy machinery, tools, and lighting on-site, enhancing productivity and safety.

Remote Locations: Whether it's a remote research station, a mobile clinic, or a remote telecommunications tower, the APD 25 BD can provide a consistent source of electricity in off-grid locations.

Emergency Services: Hospitals, fire stations, and emergency response centers rely on uninterrupted power. This generator can be a lifeline during emergencies, ensuring that critical equipment and systems remain operational.

Events and Outdoor Activities: The APD 25 BD can also be used for outdoor events, concerts, or even in recreational vehicles, providing the necessary power for lighting, sound systems, and other equipment.

Conclusion

The APD 25 BD diesel generator is a powerful and adaptable solution for a variety of power generation needs. Its combination of efficiency, durability, and versatility makes it a popular choice in residential, commercial, and remote settings. Whether you need a reliable backup power source for your home or a dependable solution for an industrial site, the APD 25 BD can meet your power needs. With its commitment to delivering consistent electricity, this generator is truly powering a world of possibilities.
