Full Specification of APD 2750 BD Diesel Generator With Details Guide!
- Product: AKSA (Powered by Baudouin)
- Alternator: AK 72000
- CONTROL SYSTEM: DSE 7320
Aksa power generation system, providing optimum performance, and reliability, for stationary standby, prime power, and continuous duty applications. All generator sets are factory build, and production tested.
Certificate
- TS ISO 8528
- CE
- SZUTEST
- 2000/14/EC
General Characteristics
Model Name | APD 2750 BD |
Frequency (Hz) | 50 |
Fuel Type | Diesel |
Engine Made and Model | AKSA (Powered by Baudouin) - A12CRW657TWG1-12M55G2750/5 |
Alternator Made and Model | Aksa - AK 72000 |
Control Panel Model | DSE 7320 |
Canopy | AK 99 |
3 Phase, 50 Hz, PF 0.8
VOLTAGE | STANDBY RATING (ESP) | PRIME RATING (PRP) | Standby Amper | ||
kVA | kW | kVA | kW | ||
400/231 | 2750 | 2200.00 | 2500 | 2000.00 | 3969.40 |
STANDBY RATING (ESP) : Applicable for supplying power to varying electrical load for the duration of power interruption of a reliable utility source. ESP is in accordance with ISO 8528-1. Overload is not allowed.
PRIME RATING (PRP) : Applicable for supplying power to varying electrical load for unlimited hours. PRP is in accordance with ISO 8528-1. 10 % overload capability is available for a period of 1 hour within 12-hour perod of operation.
ENGINE SPECIFICATIONS
Engine | AKSA (Powered by Baudouin) | |
Engine Model | A12CRW657TWG1-12M55G2750/5 | |
NO. OF CYLINDERS AND BUILD | 12 cylinders - V type | |
BORE AND STROKE | mm | 180 X 215 |
TOTAL DISPLACEMENT | L | 65.65 |
Aspiration | Turbo Charged and Aftercooled (Air to Water) | |
COMPRESSION RATIO | 16.5:1 | |
RATED SPEED (RPM) | d/dk | 1500 |
OIL CAPACITY | L | 460 |
Standby Power (kW/HP) | 2450/3286 | |
Prime Power | 2200/2950 | |
Block Heater QTY | 2 | |
Block Heater Power (Watt) | 3000 | |
Fuel Type | Diesel | |
Injection Type and System | Direct | |
Type of Fuel Pump | HPCR (High Pressure Common Rail) | |
Governor System | ECU | |
Operating Voltage (Vdc) | 24 Vdc | |
Battery and Capacity (Qty/Ah) | 4x200 | |
Charge Alternator (A) | 55 | |
Cooling Method | Water Cooled | |
Coolant Capacity (engine only / with radiator) (lt) | 306/526 | |
Air Filter | Dry Type | |
Fuel Cons. Prime With %100 Load (lt/hr) | 513.9 | |
Fuel Cons. Prime With %75 Load (lt/hr) | 393.2 | |
Fuel Cons. Prime With %50 Load (lt/hr) | 263.5 |
ALTERNATOR SPECIFICATIONS
Manufacturer | Aksa | |
Alternator Made and Model | AK 72000 | |
Frequency (Hz) | Hz | 50 |
Power (kVA) | kVA | 2500 |
DESIGN | Brushless | |
VOLTAGE | V | 400 |
Phase | 3 | |
A.V.R. | MX341 | |
Voltage Regulation | (+/-) | 1 |
Insulation System | H | |
Protection | IP22 | |
Rated Power Factor | 0.8 | |
WEIGHT COMP. GENERATOR (Kg) | 4760 | |
COOLING AIR (m³/min) | m3 | 161.4 |
SIZE and WEIGHT
Open Type | DRY WEIGHT (kg.) | LENGTH | WIDTH | HEIGHT | TANK CAPACITY (lt.) (Lt.) |
CANOPY | DRY WEIGHT (kg.) | LENGTH | WIDTH | HEIGHT | TANK CAPACITY (lt.) (Lt.) |
AK 99 | 9000 | 2800 | 3456 | 2200 |
STANDARD SPECIFICATIONS
Water cooled diesel engine
Radiator with mechanical fan
Protective grille for rotating and hot parts
Electric starter and charge alternator
Starting battery (with lead acid) including rack and cables
Engine coolant heater
Steel base frame and anti-vibration isolators
Spare external fuel tank (open set)
Flexible fuel connection hoses
Single bearing, class H alternator
Industrial exhaust silencer and steel bellows supplied separately
Static battery charger
Manual for application and installation
Generators Sets’ voltage and frequency regulation comply with ISO 8528-5
OPTIONAL EQUIPMENTS
ENGINE
• Fuel-Water Seperator Filter• Oil heater
ALTERNATOR
• Anti-Condensation Heater• Over sized alternator
• PMG excitation + AVR
• Main line circuit breaker
CONTROL SYSTEM
• Automatic synchronising and power control system ( multi gen-set Parallel )• Transition synchronization with mains
• Remote annunciator panel
• Remote relay output
• Alarm output relays
• Remote communication with modem
• Earth fault, single set
• Charge Ammeter
TRANSFER SWITCH
• Three Pole Contactor• Four Pole Contactor
• Three or four pole motor operated circuit breaker
OTHER ACCESSORIES
• Main Fuel Tank• Automatic or manual fuel filling system
• Manual oil drain pump
• Electrical oil drain pump
• Low and high fuel level alarm
• Residential silencer
• Enclosure: weater protective or sound attenuated
• Duct adapter ( on radiator)
• Inlet and outlet motorised louvers
• Inlet and outlet acoustic baffles
• Trailer
• Tool kit for maintenance
• Automatic transfer switch
Empowering Bangladesh: The Aksa APD2750BD Diesel Generator
In Bangladesh, where power outages are a common occurrence, having a reliable source of backup power is not just a convenience but a necessity for businesses, industries, and essential services. The Aksa APD2750BD diesel generator is a powerhouse engineered to meet these challenges head-on, offering exceptional performance and efficiency. In this comprehensive blog article, we will dive deep into the world of the Aksa APD2750BD diesel generator, exploring its applications, features, and pricing within the context of Bangladesh.
Aksa APD2750BD Diesel Generator: The Power Solution
The Aksa APD2750BD is a high-capacity diesel generator that represents the pinnacle of Aksa Power Generation's product line. Aksa, a globally recognized leader in power solutions, has meticulously designed this generator with the aim of ensuring a dependable and uninterrupted power supply, making it an optimal choice for a diverse range of applications.
Key Features and Specifications
- Engine: The APD2750BD is equipped with a robust and fuel-efficient diesel engine, guaranteeing a stable power supply even in challenging conditions.
- Control Panel: It features an advanced control panel with a user-friendly interface, allowing for easy operation and real-time monitoring of the generator's performance.
- Soundproof Enclosure: Many models come with a soundproof enclosure, substantially reducing noise levels, and making it suitable for urban areas and noise-sensitive environments.
- Automatic Start/Stop: The generator often incorporates an automatic start/stop function, ensuring a seamless transition to backup power during outages.
- Fuel Efficiency: Aksa generators are celebrated for their fuel efficiency, leading to cost savings during extended operation.
- Emissions Compliance: The APD2750BD complies with international emissions standards, contributing to a cleaner and more eco-friendly power source.
Applications of Aksa APD2750BD Diesel Generator
The Aksa APD2750BD diesel generator is versatile and suitable for a wide array of sectors and industries, including:
- Manufacturing: Ensuring an uninterrupted power supply for manufacturing facilities, guarding against costly production downtime.
- Hospitals and Healthcare Facilities: Critical for healthcare institutions where a consistent power supply is essential for patient care and the operation of vital medical equipment.
- Data Centers: Vital for data centers to maintain business continuity, protecting against data loss and operational disruptions.
- Telecommunications: Ensuring the continuous operation of communication networks during power outages, facilitating uninterrupted connectivity.
- Construction Sites: Providing power for construction equipment and tools, especially in remote or off-grid locations.
Aksa APD2750BD Diesel Generator Price in Bangladesh
The price of the Aksa APD2750BD diesel generator in Bangladesh can vary based on factors such as configuration, optional accessories, and additional features. As of my last knowledge update in September 2021, the price typically ranged from ৳45,000,000 to ৳55,000,000 for a new unit.
It's important to note that prices may fluctuate over time due to factors such as currency exchange rates, changes in demand, and market conditions. For the most accurate and up-to-date pricing information, it is recommended to contact authorized Aksa generator dealers or distributors in Bangladesh.
Conclusion
The Aksa APD2750BD diesel generator is a robust and efficient solution to address the challenges posed by power outages in Bangladesh. Its exceptional features, fuel efficiency, and wide range of applications make it an attractive choice for various industries and sectors. When considering the purchase of such a generator, it's crucial to assess your specific power requirements, evaluate the cost, and consult with authorized dealers to ensure a well-informed decision for a more resilient and efficient power supply in Bangladesh. With the Aksa APD2750BD, you can play a significant role in ensuring uninterrupted power for essential services and businesses in a nation where consistent electricity supply is the cornerstone of progress and development.
