APD310C Diesel Generator in Bangladesh
EMI Available
Model: APD 310 C
Brand: AKSA
0.00 0.00

Full Specification of APD 310 C Diesel Generator With Details Guide!


  • Product: CUMMINS
  • Alternator: AK 5240
  • CONTROL SYSTEM: DSE 7320

Aksa power generation system, providing optimum performance, and reliability, for stationary standby applications. All generator sets are factory build, and production tested.


Certificate


  • TS ISO 8528
  • CE
  • SZUTEST
  • 2000/14/EC

General Characteristics

Model Name

APD 310 C

Frequency (Hz)

50

Fuel Type

Diesel

Engine Made and Model

CUMMINS - 6LTAA9.5-G3

Alternator Made and Model

Aksa - AK 5240

Control Panel Model

DSE 7320

Canopy

MS 60 CK


3 Phase, 50 Hz, PF 0.8

VOLTAGE

STANDBY RATING (ESP)

PRIME RATING (PRP)

Standby Amper

kVA

kW

kVA

kW

400/231

310

248.00

279

223.20

447.46

STANDBY RATING (ESP) : Applicable for supplying power to varying electrical load for the duration of power interruption of a reliable utility source. ESP is in accordance with ISO 8528-1. Overload is not allowed.

PRIME RATING (PRP) : Applicable for supplying power to varying electrical load for unlimited hours. PRP is in accordance with ISO 8528-1. 10 % overload capability is available for a period of 1 hour within 12-hour perod of operation.


ENGINE SPECIFICATIONS

Engine

CUMMINS

Engine Model

6LTAA9.5-G3

NO. OF CYLINDERS AND BUILD

6 cylinders - in line

BORE AND STROKE

mm

116.5 X 148

TOTAL DISPLACEMENT

L

9.50

Aspiration

Turbo Charged and Charge Air Cooled

COMPRESSION RATIO

16.6:1

RATED SPEED (RPM)

d/dk

1500

OIL CAPACITY

L

32.4

Standby Power (kW/HP)

280/375

Prime Power

250/335

Block Heater QTY

1

Block Heater Power (Watt)

3000

Fuel Type

Diesel

Injection Type and System

Direct

Type of Fuel Pump

Mechanical

Governor System

Electronic

Operating Voltage (Vdc)

24 Vdc

Battery and Capacity (Qty/Ah)

2x85

Charge Alternator (A)

70

Cooling Method

Water Cooled

Cooling Fan Air Flow (m3/min)

550

Coolant Capacity (engine only / with radiator) (lt)

11.1/65.1

Air Filter

Dry Type

Fuel Cons. Prime With %100 Load (lt/hr)

58

Fuel Cons. Prime With %75 Load (lt/hr)

44

Fuel Cons. Prime With %50 Load (lt/hr)

30


ALTERNATOR SPECIFICATIONS

Manufacturer

Aksa

Alternator Made and Model

AK 5240

Frequency (Hz)

Hz

50

Power (kVA)

kVA

300

DESIGN

  Brushless

VOLTAGE

V

400

Phase

3

A.V.R.

SX440

Voltage Regulation

(+/-)

1

Insulation System

H

Protection

IP22

Rated Power Factor

0.8

WEIGHT COMP. GENERATOR (Kg)

940

COOLING AIR (m³/min)

m3

29.16


SIZE and WEIGHT

Open Type

DRY WEIGHT (kg.)
(kg.)

LENGTH
(mm.)

WIDTH
(mm.)

HEIGHT
(mm.)

TANK CAPACITY (lt.) (Lt.)

2660

2840

1300

1845

470

CANOPY

DRY WEIGHT (kg.)
(kg.)

LENGTH
(mm.)

WIDTH
(mm.)

HEIGHT
(mm.)

TANK CAPACITY (lt.) (Lt.)

MS 60 CK

3350

3963

1356

2171

470


STANDARD SPECIFICATIONS

Water cooled, Diesel engine
Radiator with mechanical fan
Protective grille for rotating and hot parts
Electric starter and charge alternator
Starting battery (with lead acid) including rack and cables
Engine coolant heater
Base frame design incorporates an integral fuel tank and anti-vibration isolators
Flexible fuel connection hoses
Single bearing, class H alternator
Industrial exhaust silencer and steel bellows supplied separately(for open sets)
Static battery charger
Manual for application and installation

OPTIONAL EQUIPMENTS

ENGINE

  • Fuel-Water Seperator Filter
  • Low water level alarm
  • Oil heater
ALTERNATOR

  • Anti-Condensation Heater
  • Main line circuit breaker
CONTROL SYSTEM

  • Earth fault, single set
  • Charge Ammeter
TRANSFER SWITCH

  • Three Pole Contactor
  • Four Pole Contactor
  • Three or four pole motor operated circuit breaker

OTHER ACCESSORIES

  • Main Fuel Tank
  • Automatic or manual fuel filling system
  • Manual oil drain pump
  • Low and high fuel level alarm
  • Enclosure: weater protective or sound attenuated
  • Trailer
  • Tool kit for maintenance

Powering Bangladesh: The APD310C Diesel Generator

In Bangladesh, where power outages are a frequent reality, having a reliable source of backup electricity is not just a convenience but a necessity. The APD310C Diesel Generator is gaining recognition as a dependable solution to tackle these power disruptions. In this blog post, we will delve into the key features and benefits of the APD310C Diesel Generator and discuss why it is swiftly becoming the preferred choice for ensuring a continuous power supply in Bangladesh.

Key Features of the APD310C Diesel Generator:

  1. High Power Output: The APD310C is a powerhouse of a generator, boasting an impressive capacity of [X] kilowatts. This substantial power output makes it suitable for a wide range of applications, from households and small businesses to industrial facilities.
  2. Sturdy Diesel Engine: Equipped with a durable and fuel-efficient diesel engine, the APD310C ensures both long-lasting performance and cost-effective operation. Diesel engines are known for their reliability, making them an excellent choice in regions with frequent power interruptions.
  3. Automatic Transfer Switch (ATS): The built-in ATS system ensures a seamless transition between the main power supply and the generator, ensuring that your home or business remains operational even during sudden power failures.
  4. Low Noise Operation: The APD310C is designed with noise reduction in mind, operating quietly to minimize noise pollution. This attribute makes it an ideal choice for urban and residential areas where noise can be a concern.
  5. Fuel Efficiency: The APD310C is engineered for fuel efficiency, leading to significant long-term cost savings. In a country where electricity prices can be high, this is an appealing advantage.

Why Choose the APD310C Diesel Generator in Bangladesh?

  1. Reliable Power Supply: Bangladesh's power grid often experiences instability, leading to frequent power cuts. The APD310C offers a dependable backup power source, ensuring an uninterrupted power supply to keep your daily operations running smoothly.
  2. Economic Viability: While the initial investment in a generator may seem substantial, it can lead to substantial cost savings over time. Diesel generators, like the APD310C, are known for their fuel efficiency, making them an economically sound choice.
  3. Versatility: The APD310C is designed to cater to a wide array of power requirements, from small households to large industrial setups. Its high power output and adaptability make it suitable for diverse applications.
  4. Environmental Responsibility: Modern diesel generators, including the APD310C, adhere to strict emissions standards and incorporate technologies that reduce harmful emissions. This ensures reliable power without compromising on environmental responsibility.

Conclusion

The APD310C Diesel Generator stands as a robust solution to the persistent problem of power outages in Bangladesh. With its substantial power output, durable diesel engine, automatic transfer switch, low noise operation, and fuel efficiency, it provides a reliable and cost-effective source of backup electricity. By choosing the APD310C, you can ensure an uninterrupted power supply for your home, business, or industrial operations, regardless of the challenges posed by the power grid.

Investing in the APD310C is a step toward powering progress and prosperity for Bangladesh. It signifies a commitment to reliability and a brighter, more electrified future, where people and industries can continue to thrive, even in the face of power challenges.
